RHTEC Split Type UV Laser Marking Machine
The UV laser marking machine, also known as UV laser marking equipment, utilizes ultraviolet laser technology to achieve high-precision marking on material surfaces through controlled laser-induced oxidation or ablation.
UV marking machine is mainly used for ultra-fine marking, and some special materials’ marking, engraving and cutting.
The machine is suitable for marking on most metal and non-metal materials. It is widely applied in ultra-fine laser marking in high-end market.
Advantages:
High adaptability: Suitable for various materials, including plastics, glass, wood, stone and metals, especially for applications requiring ultra-fine markings.
Non-contact processing: Ensures minimal heat-affected zones, preserving material integrity.
Model | RH-U |
Laser Power | 3W/5W/10W |
Working area | 70*70-200*200mm(Optional) |
Wavelength | 355nm |
Beam Quality | <2M2 |
Min Line Width | <0.01mm |
Mini line speed | <0.01mm |
Min Character | 0.12mm |
Marking Speed | ≤10000mm/s |
Marking Depth | ≤0.5mm |
Repeat Precision | ±0.001mm |
Power Supply | 110v/220V(±10%), 50/60Hz |
Cooling Style | Air Cooling/Water Cooling |
Working Environment | Clean and Dust Free |
Operating Temperature | 10℃-35℃ |
Humidity | 5% to 75% (Free of Condensed Water) |
Gross Power | <1200W |
Warranty | 12 Months |
